Famovape Magma Box mod review by Mjag...Better Voopoo Drag?

Thanks for checking out my review of the Famovape Magma Box mod which was provided directly from Famovape.

Specs:

  • Dimension: 8748.525mm
  • Material: Zinc Alloy
  • Display: 0.96 inch TFT color screen
  • Power range: 5-200W
  • Temperature range: 100℃-300℃/200℉-570℉
  • Input Voltage: 6.4V-8.4V
  • Output Voltage: 1.0V-7.5V
  • Max output current: 40A
  • Battery Capacity: Dual 18650
  • Power Mode POWER/SS/NI/TI
  • Minimum Resistance: 0.08 ohms
  • Atomizer resistance range: 0.08-3.0
  • Supported Wire materials: ss/ni200/Ti
  • USB charge: USB charge: DC 5V/2A

Package Includes:

  • Magma Box Mod
  • Warranty Card
  • User Card
  • USB Cable

Available in multiple colors:

Getting to know the Famovape Magma mod

Famovape is not new but may be new to you, me as well since this is the first product from them I have ever had. A friend of mine had picked up the Magma mod and I have to admit, I liked the look of his blue resin mod so when they approached me I agreed to a review. I was also VERY impressed with Famovape when they read a post and responded: Think Before Buying The Famovape Magma UPDATE! - #15 by famovape . I don’t think I have personally ever seen a mfg respond like that and hope they keep it up.

I asked for the blue resin panel and as a backup, in case the blue resin wasn’t available, the black and white Shadow version. Guess the blue was out but to my surprise, they sent the Arcanom (blue/green/purple) and also the Shadow.

Lucky me, someone had given me a purple tank awhile back so finally have a mod to match……Win!

One of the first things I noticed was the purple Arcanom version has a decent amount of button rattle, both the up/down and fire button. The black/white Shadow has no button rattle, maybe the Arcanom version is a prior run and they fixed the button rattle in the later Shadow version? Seems odd but aside from a little different text on the bottom they appear identical, aside from color.

The 510 plate is slightly raised over the body, good for not scratching the paint but bad if you detest a small gap under your tank. Doesn’t look bad to me but something that should be pointed out.

Aside from the button rattle on the Arcanom purple version, it is a solid feeling mod. A little play on the battery door if you slide it with your thumb up/down and side to side but does not move unless you intentionally try to.

The 510 made good contact with every tank I tried and read the ohms pretty spot on. Not a lot of throw on the 510 pin but never encountered a problem with it. I do know the first run was afflicted with a 510 problem so I am glad they addressed it, gotta give a company props for addressing a problem and fixing it. I know my friends 510 was faulty and they sent him a replacement after they saw his post on a forum, very impressed with that.

It is a simple yet solid mod but I still had to partially take it apart. I get joy giving Steampugs more nightmares of what I would do to his mods if he ever left them in my care……muhahahaha…

Wasn’t able to get a good pic of the 510 innards as the connecting wires are short. What I did see looks solid though.

Nice and bright screen and you can change the color if you want.

The menu system is simple enough, 3 clicks and you’re in to select modes like Watts, Ni, Ti, SS TC and Bypass. You can also select the color of the screen and clear your puff counter, that’s it. To adjust wattage in TC is it 2 clicks of the fire button but you are limited to 80 watts….ugh.

Not the most comfortable to hold but a lot better than the original Drag mod, I would choose the Magma over the original Drag every time.

Overall I feel it is a clean looking mod and the fit and finish on both are clean and remained so during my 3 weeks + evaluation time.

So how does it perform?

In power mode, it hits quick, no complaints there. There are no preheat modes or power curves, if any of that is a must-have for you then you won’t be happy. I do use preheat on a lot of my mods but found that it hits fast enough that I did not mind in normal use. Took it all the way up to 200 watts with a triple coil build in my Titan tank and felt the same as my DNA250C mod, not bad. One thing that is annoying though is when you attach a new tank it asks if it is a new or old coil. Select new and it defaults to 20 watts, select old and it keeps the wattage you had set before. That does not happen in TC mode, those settings stay the same. The watts adjust in 1-watt increments and goes fairly quick, it took 11 seconds to go from 5 watts to 200 watts.

My first TC test with matching RDA’s using the same single coil SS316L build was positive. It did hit on the cool side, had to adjust my temp up 20F to match my SXmini G Class. Even at the higher temp it still offered great dry hit protection which was smooth. Adjusting the TCR from the preset 0092 I found it came a lot closer between 0100 and 0110 depending on the build. Switching to a dual coil build in an RTA I found that it was a close match to my G Class at the same temp, didn’t have to adjust the temp up 20F to get the same vape and kept my TCR at 0092…Took it along with me to meet up with friends on a hot sunny day and that is when I ran into trouble with TC. I had to switch it out of TC and into watts to get a good vape, it did not compensate for the 100 degree heat outside.

For power mode users I think you will be satisfied unless you need to have some preheat or power curve settings. For TC users, if you’re like me and want consistency, then this might not be for you. It is definitely not a bad TC mod but on a hot day you may run into problems and I assume it might be the same for a cold day. The variances depending on the build might bother some, I just adjusted my temp or TCR until I got what I wanted but I see myself using this more in power mode going forward. The 80 watt TC limit annoys me just like it does with Voopoo mods, why limit it? I do have some builds that need 95+ watts to get what I am after. It was apparent with some builds that will never go on the Magma for TC, just can’t get the initial ramp-up I want.

I did not measure the battery life but in everyday use never felt like the battery life was bad at all. It never even occurred to me to check the puffs I could get on a full set of batteries as it was never a problem in 3+ weeks of usage. No passthrough charging, if you are driving and need a charge you will not be able to vape while charging.

Pros:

  • Simple to use with an intuitive menu system
  • Fires quick in power mode and 200 watts fired the same as my DNA250C mod
  • Consistent ohm readings that were generally accurate
  • Solid mod, feels like quality in the hand
  • Bright and easy to read screen
  • Watts are adjusted in 1-watt increments, does anyone really need 56.4 watts?
  • Excellent customer service, they saw my friends post in a forum on the faulty 510 from the first run. They corrected it in there next run and sent him a replacement

Cons:

  • No preheat, power curve or TC curve modes
  • Defaults to 20 watts when installing a new tank in power mode
  • Button rattle on one sample but not the other, hoping it is a problem they fixed and the one with rattle is the prior run
  • Watts are limited to 80 in TC mode, will limit performance with bigger TC builds
  • TC is not consistent from build to build and greatly affected by weather
  • Not firmware upgradable (I looked but could not find any info on that)
  • No passthrough charging

Final thoughts

In normal everyday use I enjoyed using the Famovape Magma, just ran into a problem on these really hot summer days when using TC. The TC can be good and offers great dry hit protection but it is not consistent from build to build. I still might use it from time to time for TC but power mode is preferred overall. In power mode, my only cons are no preheat or power curve options but it still fires fast and felt accurate. The default to 20 watts when installing a new tank is ANNOYING, that kept bugging me.

I can definitely see the Magma as a great replacement for those with an original Voopoo Drag. It is definitely more comfortable to hold and the performance is a match or possibly better. I gave away my Drag mod so could not do a direct comparison, the funny thing is my friend I gave the Drag to wound up giving it away himself.

I am mixed on if I would recommend the Famovape Magma. On one hand, if someone just wants a power mode mod that hits quick and delivers without all the extra fuss of a preheat mode or power curves then sure, the Magma fits the bill. If someone likes to have options and consistent TC then the Magma will not be what I recommend, mods that offer those options generally come at a higher price though.

I can see myself continuing to use the Famovape Magma after this review, the Shadow version at least. I think it looks cool and the performance in power mode will keep me happy. I was looking to buy the Blue version my friend had prior to being asked to review it so that is saying something.

You can find more info and even purchase it directly from Famovapes website: Magma Box - 200W Box Mod – famovape

Check out how this stacks up to other tasty gear and meet the Steampugs team of reviewers. Your bound to have a good time and read up on some great products, not so great ones too http://www.steampugs.co.uk/

9 Likes

Who is this nameless friend you keep referencing? And no, you can’t have my Ocean Deep color Magma. I had to do a lot of arm twisting at my local vape shop to get that! Great review man.

5 Likes

Hmmmm, I don’t know, keep forgetting his name, sort of an insane enabler anyway :wink: :grin:

Cmon man, I got 2 beauuuuuutiful Magma’s to trade for your blue, I stack em deep and trade em cheap, if you don’t take this offer we are both CRAZY :crazy_face:

Now I am off to read your review if my phone doesn’t ring again, people are cray-cray, I get bored hearing myself talk so why they call me is a riddle wrapped up in a conundrum…I don’t even know what that means :thinking:

6 Likes

This is your problem:

2 Likes

I have to admit, I look a LOT better animated :grin:

2 Likes

Sounds like a good basic mod. There’s something to be said about that. I still have an old Segelei 213 that I use quite often. Doesn’t do anything special. Wattage only as per dysfunctional TC. Doesn’t achieve what it claims even in VW but… It is comfortable, reliable, and small. Batteries don’t fall out the bottom. 510 stays solid. It’s like a good pistol. Pull the trigger it goes bang, every time. End of the day, that’s all that’s necessary.

5 Likes

Funny you mention it but yeah, I used my Sig 155…errrr 213 all the time too, it held up great and a mod I will keep around for sure as it was always solid despite the flaws you mentioned.

I just finished watching DJLSB review on the Magma and wow did they have a mess on there hands when he got his. The changes they made sure makes for a much better mod than what Daniel and @Jim22 received. I commend them on making fixes but better beta testing beforehand would have made more sense. Still, a very classy way they handled it in an industry that usually doesn’t care. For that reason alone I will give them my busy in the future, they earned a lot of brownie points with me in how they handled it.

3 Likes

That is HUGE! Anybody can have issues at release. It’s what you do with the issues that count.

4 Likes
